Choosing the correct flange type is not just a "parts selection" task—it directly affects sealing reliability, safety, inspection requirements, installation time, and total cost of ownership. In this guide, we'll walk through a practical, engineering-oriented process to select the right flange type, facing, rating, and stainless steel grade for your application.
Before you pick between Weld Neck (WN) or Slip-On (SO), confirm the application requirements. Most selection mistakes happen because one of these items was missing or assumed.
Fluid / medium: water, steam, oil & gas, chemicals, seawater, food-grade, etc.
Design pressure & design temperature (not only normal operating values)
Thermal cycling, vibration, or fatigue considerations
Corrosion risks: chlorides, pitting/crevice corrosion, stress corrosion cracking (SCC), external corrosion under insulation (CUI)
Pipe size: NPS/DN
Pipe schedule / wall thickness
Standard system: ASME / EN / JIS / etc. (avoid mixing without verification)
Connection preference: butt weld, fillet weld, threaded, or lap joint
Facing type: RF / FF / RTJ
Gasket type: spiral wound, ring gasket, sheet gasket, etc.
Inspection / documentation needs: PMI, NDT, dimensional inspection, MTC (EN 10204 3.1/3.2)
Tip: If you're sourcing for multiple sites or contractors, define a "standard flange specification" early. It prevents costly mismatches later.
Below are the most common flange types used in industrial piping. The "best choice" depends on load, fatigue, leak tightness requirements, and installation constraints—not only price.
Best for: high pressure, high temperature, critical service, cyclic loads
Why it works: the long tapered hub provides excellent stress distribution and strong butt-weld integrity.
Typical applications: steam lines, high-pressure process lines, refineries, power plants, critical chemical service.
Considerations:
Usually higher cost than Slip-On
Requires qualified butt welding and inspection practices
Best for: low to medium pressure, general service, where cost and easy fit-up matter
Why it works: slides over the pipe and is fillet welded—easy alignment during installation.
Typical applications: utility lines, water systems, low-risk industrial piping.
Considerations:
Lower fatigue strength than Weld Neck
Typically needs welding on both sides for reliability (per project practice/spec)
Best for: small-bore, high-pressure lines (often instrumentation and small process piping)
Why it works: pipe is inserted into a socket and fillet welded, giving a strong joint in compact sizes.
Typical applications: high-pressure small diameter services, hydraulic/process connections.
Considerations:
Can create a crevice at the socket area; not ideal for some corrosive or hygienic services
Usually limited to smaller sizes
Best for: non-weld applications or where welding is restricted
Why it works: threads connect the flange to the pipe without welding.
Typical applications: certain maintenance-friendly systems, low temperature/pressure utility lines.
Considerations:
Not recommended for high vibration, high temperature, or severe cyclic conditions
Seal integrity depends on thread quality and sealing method
Best for: systems requiring frequent dismantling, alignment flexibility, or use with expensive alloy piping
Why it works: the lap joint flange rotates around the stub end, making bolt alignment easy.
Typical applications: maintenance-intensive lines, some corrosive service systems where flange reuse is desired.
Considerations:
Generally lower pressure capability than Weld Neck in many systems
Requires correct stub end selection (material, dimensions, facing)
Best for: line termination, isolation points, pressure testing, future expansion points
Why it works: closes the end of a pipeline or valve opening with a bolted seal.
Typical applications: piping ends, spare nozzles, test points, manifolds.
Considerations:
Proper thickness, bolt load, and gasket selection are critical
Access and safe handling matter (blinds can be heavy)
The flange type alone doesn't guarantee sealing performance. Facing selection must match the standard, gasket, and operating conditions.
Most common in many ASME-based systems.
Works with a wide range of gaskets (e.g., spiral wound)
Suitable for many industrial services
Often used for lower pressure applications and in situations where flange/connection requirements specify FF.
Commonly paired with full-face gaskets in some systems
Important: Avoid accidental RF/FF mismatches unless your engineering standard explicitly allows it.
Preferred for high pressure and/or high temperature services requiring very robust sealing.
Uses a machined groove and a metallic ring gasket (e.g., R / RX / BX styles depending on system)
Requires correct groove finish and gasket compatibility
Rule of thumb: If your project spec calls for RTJ, treat facing tolerance and machining quality as a priority—this is not a place to "optimize cost."
Flange pressure rating is not a single-number decision. It depends on:
Design pressure
Design temperature
Material group
Applicable standard rating tables
ASME classes are tied to pressure–temperature rating tables. As temperature rises, allowable pressure typically decreases.
PN is a different system than ASME class. Do not assume PN and class are interchangeable. Always confirm:
flange dimensions
bolt circle
thickness
facing details
rating rules in the relevant standard
Best practice: Specify the complete standard and designation, for example:
"ASME B16.5, NPS 4, Class 300, RF"
or "EN 1092-1, DN100, PN40, Type 11 (weld neck), RF"
For stainless steel flanges, material selection is usually driven by corrosion resistance, temperature, and compliance requirements.
304 / 304L: general industrial service; good availability and cost-effectiveness
316 / 316L: improved resistance to many corrosive environments, especially chlorides compared with 304 (but not "seawater-proof" in every condition)
Stabilized grades (e.g., 321 / 347): often considered for elevated temperature service where sensitization/intergranular corrosion risk is a concern
Duplex / higher-alloy options (if applicable): often chosen for chloride SCC resistance and higher strength requirements
For project work, buyers often require:
Material Test Certificate (MTC) per EN 10204 3.1 (or 3.2 if specified)
Heat number traceability and permanent marking
PMI (Positive Material Identification) when required by spec
If you share your standard + size + rating + facing + material + service conditions, we can help confirm the appropriate flange type and supply stainless steel flanges with the documentation your project needs.
Product range: https://www.sdflflange.com/Stainless-Steel-Flange-pl42742597.html
In many industrial piping applications, Weld Neck (WN) flanges are considered among the strongest and most reliable due to their tapered hub and butt-weld connection, especially for high pressure, high temperature, and cyclic conditions.
Choose Slip-On (SO) for general service where pressure/temperature and fatigue demands are moderate and installation simplicity matters. Choose Weld Neck (WN) for more critical service, higher loads, or where long-term reliability under cycling is a priority.
RF (Raised Face) uses a raised sealing surface and typically non-metallic or semi-metallic gaskets (like spiral wound). RTJ (Ring Type Joint) uses a machined groove and a metal ring gasket, commonly used for high-pressure/high-temperature duty.
